Radial Drill Machine

Radial Drill Machine
Radial Drill Machine
Product Code : AR40
Product Description

Radial Drill

'ARSUN' AR Series of Radial Drills are designed to offer rigidity, precision and easiness in operation.

Salient Features

  • Heavy Duty - 40-mm drilling in steel.
  • Wide range of 8 spindle speeds for drilling, tapping, reaming and boring operations.
  • Five auto power feeds: 0.05 to 0.25-mm per revolution.
  • Auto feed disengages at preset depth as well as too high or abnormal drilling pressure.
  • Hardened and lapped alloy steel gears fitted on splined shafts in main drive gearbox runs in an oil bath.
  • Hardened and precision ground spindle sleeve.
  • Double column construction for rigidity and effortless centering.
  • Arm and drill-head guide ways are precisely hand scraped for minimum play and rigid clamping of drill-head with the arm.
  • Well adequately ribbed base-plate, inner column & arm for maximum rigidity and minimum deflection.

Capacity

Drilling in Steel

mm

40

Drilling in C.I.

mm

50

Tapping in Steel

mm

24

Tapping in C.I.

mm

33

Boring in Steel

mm

80

Drilling Head

Spindle nose taper


MT4

Spindle stroke

mm

225

Nos. of spindle speed


8

Range of spindle speed

rpm

45-1150

Nos. of power feeds


5

Range of power feeds

mm/rev

0.05 -0.25

Working Range



Column sleeve diameter

mm

250

Column to spindle center min/max

mm

410 / 1135

Base plate to spindle nose min/max

mm

385 / 1135

Drilling head traverse

mm

725

Arm traverse

mm

750

Base Plate

Working surface

mm

1000 x 800

Cast T-Slots: nos / width / pitch

mm

3 / 23 / 200

Power

Main motor

kw/rpm

1.5 (2 hp) / 1440

Arm lifting motor

kw/rpm

1.1 (1.5 hp) / 1440

Weight


kg

1800

Standard Equipment

  • Spindle Motor & Arm Lifting Motor
  • Electrical suitable for 415V / 50Hz / 3Phase AC supply
  • Box Table - 550x400x400-mm size
  • 0.15 HP Coolant Pump with fittings
  • Built-in coolant tank
  • Operation & Maintenance Manual.
